Baja Designs LP4 Pro LED Light Pod, Baja Amber Driving/Combo Single, No Harness

The Baja Designs 290013 LP4 Pro combines a Baja Amber Driving/Combo main lens with dedicated Integrated Peripheral Technology (IPT) lighting in the smallest housing in the LP lineup. Baja Designs describes a 200-degree spread of usable light and Direct Ducted Cooling that routes air through the front housing over the rear heat sinks.

Configuration and included contents

• One LP4 Pro LED auxiliary light pod, Baja Amber Driving/Combo
• Four forward-projecting LEDs and four dedicated IPT LEDs
• Beam and daytime-running backlighting functions
• Black powder-coated cast-aluminum housing and bezel
• Hardcoated polycarbonate amber main lens
• Stainless-steel mounting hardware included
• Wiring harness not included
• Manufacturer part number / store SKU: 290013

This is a single LP4 Pro, not a pair or Spot version. Baja Amber identifies the main lens. Shared marketing mentions amber, red, blue and green backlight options, but this part-specific record does not identify the supplied backlight color. Those options are not represented as selectable modes or included alternate components. High/low operation is not established by the record.

Detailed per-light specifications

• Primary brightness field: 8,857 lumens
• Main listed electrical draw: 75.9W / 5.5A
• Separately listed IPT output: 1,972 lumens
• Separately listed IPT draw: 15W / 1A
• Separately listed backlight draw: 4.83W / 0.35A
• DT06-4S Deutsch mating connector
• Built-in overvoltage protection

Manufacturer-data discrepancy: Marketing states a total of 8,750 lumens, composed of 7,050 forward lumens and 1,700 IPT lumens. Detailed attributes instead list 8,857 in the primary brightness field and 1,972 IPT lumens. These sets are presented separately rather than reconciled or combined into a new total. The marketing total already includes its stated IPT contribution. Confirm current ratings with Baja Designs if output or electrical sizing is critical. An input-voltage range is not supplied.

Dimensions and cooling

• Length: 5.1 inches
• Height: 5.1 inches
• Depth: 3.2 inches
• Light weight: 2.8 lb
• Manufacturer-listed average rated life: 49,930 hours

Dimensions and weight describe the light, not its shipping package. Direct Ducted Cooling supports heat dissipation by directing air over the rear heat sinks.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to Baja Designs

Installation and separate wiring

Universal fitment does not establish a vehicle-specific bracket or plug-and-play electrical connection. Confirm clearance, electrical compatibility and suitable wiring, and follow the manufacturer's instructions. This auxiliary pod is not represented as a DOT headlight replacement.

Separately listed compatible wiring products are 640168 (Controller Module Harness), 640175 (splitter, two-light maximum), 640176 (Backlit Add-On Harness), 640188 (single-light Upfitter Harness) and 640189 (splitter, four-light maximum). None is included with this light.

Optional accessories

Separate rock guards are 298001 (black), 298002 (amber) and 298003 (clear). Optional lens kits are 668701 (clear Spot), 668703 (clear Driving/Combo) and 668713 (amber Driving/Combo). Anti-theft hardware 660302 and 660303 is also listed separately. These accessories are not included contents.

Manufacturer coverage

Baja Designs lists a Limited Lifetime Warranty, subject to its terms.

Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
