Baja Designs LP9 Pro LED Light Pod, Clear Spot Single, No Harness

The Baja Designs 320001 LP9 Pro combines a clear Spot forward beam with dedicated Integrated Peripheral Technology (IPT) lighting. Nine forward-projecting LEDs and six peripheral LEDs provide a manufacturer-described 200-degree spread of usable light. This universal auxiliary pod is sold individually with stainless-steel mounting hardware; a wiring harness is not included.

Configuration and contents

• One LP9 Pro LED auxiliary light pod
• Clear main lens with Spot beam pattern
• Nine forward LEDs plus six dedicated IPT LEDs
• High-power, low-power and daytime-running backlight modes
• Black powder-coated cast-aluminum housing and bezel
• Hardcoated polycarbonate lens
• Stainless-steel mounting hardware included
• Wiring harness not included
• Manufacturer part number and store SKU: 320001

This is the clear Spot version, not the Driving/Combo model. Clear identifies the main lens; the record does not specify backlight color. This is an auxiliary light, not a DOT headlight replacement.

Output and electrical specifications

• Manufacturer-listed total output: 12,547 lumens per pod
• Main listed electrical rating: 124.2W / 9A
• Separately listed IPT output: 2,302 lumens
• Separately listed IPT draw: 21W / 1.52A
• Separately listed backlight draw: 2.8W / 0.2A
• DT06-4S Deutsch mating connector
• Built-in overvoltage protection

Marketing describes 12,547 lumens as total output, so the separately listed IPT lumens are not added again to that figure. Electrical ratings are reproduced by their source labels, not summed into an assumed simultaneous total. The record does not provide input-voltage limits or separate low-power output and draw.

Physical specifications and cooling

• Length: 8 inches
• Height: 8 inches
• Depth: 3.25 inches
• Weight: 6.5 lb
• Manufacturer-listed average rated life: 49,930 hours

Direct Ducted Cooling allows air to travel from the front of the housing to the rear to support heat dispersion. These dimensions describe the light rather than its shipping package.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to the manufacturer

Installation and separate accessories

Confirm mounting clearance, electrical compatibility and appropriate wiring before installation. Universal fitment does not establish a vehicle-specific bracket or plug-and-play connection. Follow the manufacturer's installation instructions.

Separately listed compatible products include upfitter lock-out harness 640167, controller-module harness 640168, two-light-maximum splitter harness 640172 and backlight add-on harness 640176. None is included with this single pod.

Optional accessories include rock guards 328001 (black), 328002 (amber) and 328003 (clear); lens kits 668601 (clear Spot), 668603 (clear Driving/Combo), 668611 (amber Spot) and 668613 (amber Driving/Combo); and anti-theft hardware 660302 and 660303. These are separate accessories, not included contents.

Manufacturer coverage

The manufacturer lists a Limited Lifetime Warranty, subject to its terms.

Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
