Baja Designs OnX6+ 20-Inch Straight LED Light Bar, Clear Driving/Combo, High/Low, No Harness

The Baja Designs 452003 OnX6+ is a straight 20-inch LED light bar with clear lenses and a Driving/Combo beam. Twelve LEDs and high/low lighting modes provide manufacturer-listed output of 24,920 lumens on high and 18,460 lumens on low. Mounting brackets are included; a wiring harness is not.

Configuration and application

• One OnX6+ straight 20-inch LED light bar
• Beam pattern: Driving/Combo
• Clear hardcoated polycarbonate lenses; black housing
• High Beam/Low Beam lighting modes
• Universal application; confirm mounting space and electrical compatibility
• Manufacturer part number / store SKU: 452003

Shared marketing discusses a High Speed Spot reflector, but the exact product description and specifications identify this bar as Driving/Combo, not a Spot-only model.

Part-specific specifications

• Complete-bar output: 24,920 lumens on high; 18,460 lumens on low
• Power: 216W on high; 160W on low
• Current draw: 16.6A on high; 12.0A on low
• LED quantity: twelve
• Dimensions: 20 inches long × 2.69 inches high × 4.29 inches deep
• Weight: 7.85 lb
• Average rated life: 49,930 hours
• Built-in overvoltage protection

These output and electrical figures describe the complete bar. Shared marketing quotes 39,430 lumens and an up-to-69% improvement over a previous generation. That generic figure does not match this 20-inch bar's detailed high/low ratings, so it is not presented as this bar's output. The record does not specify an operating voltage range.

Construction and durability

• Aircraft-grade aluminum housing with Mil-Spec hard anodize
• Billet-machined aluminum bezel
• Hardcoated polycarbonate lenses
• Stainless-steel mounting hardware; mounting brackets included
• Manufacturer-listed durability: exceeds MIL-STD810G testing
• Manufacturer-listed impact resistance: IK10
• Manufacturer-listed water resistance: IP69K, described as waterproof up to 9 feet and pressure washable

Wiring and separately available accessories

No wiring harness is included. The manufacturer explicitly identifies the separately available 640115 On/Off OnX6+ harness for 10–20-inch bars. It also lists 640119 Hi/Low wiring and 640094 upfitter wiring as compatible accessories. Choose wiring appropriate for the desired controls and follow the manufacturer's installation instructions.

A specification field says “Hi-Low Dongle,” but the harness-included field explicitly says No; that description is not a promise of an included complete harness. The 618001 cradle mount kit, covers, rock guards, replacement lens kits, anti-theft hardware and harness splitters are listed as accessories or associated products rather than included contents.

Manufacturer coverage

Baja Designs lists a Limited Lifetime Warranty and a 30-day money-back Satisfaction Guarantee, subject to its terms.
