Baja Designs LP9 Sport LED Light Pod, Baja Amber Driving/Combo Single, No Backlight or Harness

The Baja Designs 350013 LP9 Sport combines a Baja Amber Driving/Combo main lens with Integrated Peripheral Technology (IPT) lighting for a manufacturer-described 200-degree spread of usable light. This full-size auxiliary pod offers simple on/off operation without the high/low modes or amber backlit feature of LP9 Pro and Racer Editions. The amber main lens is not a backlight.

Configuration and included contents

• One LP9 Sport LED light pod, Baja Amber Driving/Combo
• Nine forward-projecting LEDs and six dedicated IPT LEDs
• On/off operation only: no high/low modes and no amber backlight
• Black powder-coated cast-aluminum housing and bezel
• Hardcoated polycarbonate amber lens
• Stainless-steel mounting hardware included
• Wiring harness not included
• Manufacturer part number / store SKU: 350013

This is the Sport Driving/Combo single, not the Spot version, LP9 Pro or Racer Edition. Universal fitment does not establish a vehicle-specific mounting bracket or plug-and-play electrical connection.

Output and electrical specifications

• Detailed primary brightness field: 9,421 lumens per light
• Main listed draw: 88.32W / 6.4A
• Separately listed IPT brightness: 2,302 lumens
• Separately listed IPT draw: 21W / 1.52A
• DT06-4S Deutsch mating connector
• Built-in overvoltage protection

Manufacturer-data discrepancy: Shared marketing states 6,500 forward lumens at 61W and 2,280 IPT lumens at 21W. Detailed attributes instead list 9,421 in the primary brightness field, 88.32W / 6.4A and 2,302 IPT lumens. These ratings are presented separately rather than reconciled or added into a claimed total. Confirm current output and electrical ratings with Baja Designs if critical to your installation. An input-voltage range is not supplied.

Dimensions, cooling and serviceability

• Length: 8 inches
• Height: 8 inches
• Depth: 3.25 inches
• Weight: 6.5 lb
• Manufacturer-listed average rated life: 49,930 hours

Direct Ducted Cooling routes air through the housing to support cooling under load. Manufacturer-described uService technology allows lens-pattern and color changes to suit driving conditions. Dimensions above describe the light, not its shipping box.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to Baja Designs

Installation and separately sold accessories

Check mounting clearance, electrical compatibility and suitable wiring before installation, and follow the manufacturer's instructions. No wiring harness is included. This auxiliary pod is not represented as a DOT headlight replacement.

The part record lists compatible harnesses 640167 (Upfitter Lock Out), 640168 (Controller Module), 640175 (splitter, two-light maximum) and 640189 (splitter, four-light maximum). Choose wiring appropriate to the Sport's on/off operation.

Optional accessories include rock guards 328001 (black), 328002 (amber) and 328003 (clear); lens kits 668601 (clear Spot), 668603 (clear Driving/Combo), 668611 (amber Spot) and 668613 (amber Driving/Combo); and anti-theft hardware 660302 and 660303. These accessories are separate products, not included contents.

Manufacturer coverage

Baja Designs lists a 30-Day Money Back Satisfaction Guarantee and Limited Lifetime Warranty, subject to its terms.
