Baja Designs LP9 Sport LED Light Pod, Baja Amber Spot Single, No Backlight or Harness

The Baja Designs 350011 LP9 Sport combines a Baja Amber Spot main lens with Integrated Peripheral Technology (IPT) lighting for a manufacturer-described 200-degree spread of usable light. Designed for straightforward on/off operation, this full-size LP9 Sport does not include the high/low modes or amber backlit feature offered on Pro and Racer Editions. The amber main lens is not a backlight.

Configuration and included contents

• One LP9 Sport LED auxiliary light pod, Baja Amber Spot
• Nine forward-projecting LEDs and six dedicated IPT LEDs
• Simple on/off operation: no high/low modes and no amber backlight
• Black powder-coated cast-aluminum housing and bezel
• Hardcoated polycarbonate amber lens
• Stainless-steel mounting hardware included
• Wiring harness not included
• Manufacturer part number / store SKU: 350011

This is the Sport Spot single, not a Driving/Combo, Pro or Racer Edition. Universal fitment does not establish vehicle-specific brackets or a plug-and-play electrical connection.

Output and electrical specifications

• Detailed primary brightness field: 9,421 lumens per light
• Main listed draw: 88.32W / 6.4A
• Separately listed IPT brightness: 2,302 lumens
• Separately listed IPT draw: 21W / 1.52A
• DT06-4S Deutsch mating connector
• Built-in overvoltage protection

Manufacturer-data discrepancy: Shared marketing states 6,500 forward lumens at 61W plus 2,280 IPT lumens at 21W. Detailed attributes instead list 9,421 in the primary brightness field, 88.32W / 6.4A and 2,302 IPT lumens. These ratings are presented separately, not reconciled or added into a claimed total. Confirm current output and electrical ratings with Baja Designs if critical to your installation. An input-voltage range is not supplied.

Dimensions, cooling and serviceability

• Length: 8 inches
• Height: 8 inches
• Depth: 3.25 inches
• Weight: 6.5 lb
• Manufacturer-listed average rated life: 49,930 hours

Direct Ducted Cooling routes air through the housing to support cooling under load. Manufacturer-described uService technology allows lens-pattern and color changes to suit driving conditions. Dimensions above refer to the light, not the shipping box.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to Baja Designs

Installation and separately sold accessories

Check mounting clearance, electrical compatibility and suitable wiring before installation, and follow the manufacturer's instructions. No wiring harness is included. This auxiliary pod is not represented as a DOT headlight replacement.

The part record lists compatible harnesses 640167 (Upfitter Lock Out), 640168 (Controller Module), 640175 (splitter, two-light maximum) and 640189 (splitter, four-light maximum). Select wiring appropriate to the Sport's on/off operation.

Optional accessories include rock guards 328001 (black), 328002 (amber) and 328003 (clear); lens kits 668601 (clear Spot), 668603 (clear Driving/Combo), 668611 (amber Spot) and 668613 (amber Driving/Combo); and anti-theft hardware 660302 and 660303. These accessories are sold separately, not included contents.

Manufacturer coverage

Baja Designs lists a 30-Day Money Back Satisfaction Guarantee and Limited Lifetime Warranty, subject to its terms.

Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
