Baja Designs LP9 Sport LED Light Pod, Clear Spot Single, No Backlight or Harness

The Baja Designs 350001 LP9 Sport combines a clear Spot forward beam with Integrated Peripheral Technology (IPT) lighting for a manufacturer-described 200-degree spread of usable light. It offers straightforward on/off operation in a full-size LP9 housing, without the high/low modes or amber backlight of the Pro and Racer Editions.

Configuration and contents

• One LP9 Sport LED auxiliary light pod
• Clear main lens with Spot beam pattern
• Nine forward LEDs and six dedicated IPT LEDs
• Simple on/off operation, no high/low modes and no amber backlight
• Black powder-coated cast-aluminum housing and bezel
• Hardcoated polycarbonate lens
• Stainless-steel mounting hardware included
• Wiring harness not included
• Manufacturer part number and store SKU: 350001

This is the clear Spot version, not the Driving/Combo model. It is an LP9 Sport, not an LP9 Pro or Racer Edition. This auxiliary pod is not represented as a DOT headlight replacement.

Detailed output and electrical data

• Primary brightness field: 9,421 lumens per light
• Main listed electrical rating: 88.32W / 6.4A
• Separately listed IPT brightness: 2,302 lumens
• Separately listed IPT draw: 21W / 1.52A
• DT06-4S Deutsch mating connector
• Built-in overvoltage protection

Manufacturer-data discrepancy: Marketing states 6,500 forward lumens at 61W and 2,280 IPT lumens at 21W. Detailed attributes instead list 9,421 in the primary brightness field, 88.32W / 6.4A and 2,302 IPT lumens. These sets are reproduced separately rather than treated as interchangeable or combined into a claimed total. Confirm current ratings with Baja Designs if output or electrical sizing is critical. Input-voltage limits are not supplied.

Physical specifications and cooling

• Length: 8 inches
• Height: 8 inches
• Depth: 3.25 inches
• Weight: 6.5 lb
• Manufacturer-listed average rated life: 49,930 hours

Direct Ducted Cooling supports cooling by routing air through the housing. The manufacturer describes uService technology for changing lens pattern and color to suit driving conditions. These dimensions describe the light rather than its shipping package.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to the manufacturer

Installation and separate accessories

Confirm mounting clearance, electrical compatibility and suitable wiring before installation. Universal fitment does not establish a vehicle-specific bracket or plug-and-play connection. Follow the manufacturer's installation instructions.

Separately listed compatible products include upfitter lock-out harness 640167, controller-module harness 640168, two-light-maximum splitter 640175 and four-light-maximum splitter 640189. Choose wiring appropriate to the Sport's on/off operation; none is included.

Optional accessories include rock guards 328001 (black), 328002 (amber) and 328003 (clear); lens kits 668601 (clear Spot), 668603 (clear Driving/Combo), 668611 (amber Spot) and 668613 (amber Driving/Combo); and anti-theft hardware 660302 and 660303. These are separate accessories, not included contents.

Manufacturer coverage

Baja Designs lists a 30-Day Money Back Satisfaction Guarantee and Limited Lifetime Warranty, subject to its terms.

Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
