Baja Designs OnX6 Racer Edition 30-Inch Straight LED Light Bar, Clear Racer Spot, No Harness

The Baja Designs 413002 OnX6 Racer Edition is a 30-inch straight LED light bar with a clear Racer Spot beam and 18 forward-projecting LEDs. Developed for the manufacturer's race teams, this auxiliary bar supplies the Racer Spot configuration, not standard Spot or Driving/Combo.

Configuration and included contents

• One 30-inch straight OnX6 Racer Edition LED light bar
• Clear main lens, Racer Spot beam
• 18 forward-projecting LEDs
• Black aircraft-grade aluminum housing with Mil-Spec hard anodize
• Billet-machined aluminum bezel
• Hardcoated polycarbonate lens
• Stainless-steel mounting brackets / hardware included
• Wiring harness not included
• Manufacturer part number / store SKU: 413002

The manufacturer uses OnX6 Straight Racer Edition in the descriptions and OnX6+ 30 Inch Racer Edition in the product-type attribute. Both names occur in this exact part record; this is not the standard OnX6+ Driving/Combo bar.

Whole-bar specifications

• Listed electrical draw: 189W / 15.75A
• Length: 30 inches
• Height: 2.69 inches
• Depth: 4.29 inches
• Light-bar weight: 11.45 lb
• Manufacturer-listed average rated life: 49,930 hours
• Built-in overvoltage protection

These figures describe one complete bar, not each LED or the shipping package. The part record does not provide a lumen rating or input-voltage range; neither is inferred from other OnX6 models.

Wiring and installation

Harness sold separately: The manufacturer specifically identifies 640119, its high-power harness with mode switch and two-light maximum, as the applicable wiring harness. Confirm mounting clearance, electrical compatibility and control requirements, and follow the manufacturer's installation instructions. Universal fitment does not establish vehicle-specific brackets or a plug-and-play electrical connection.

The record also lists 613608 (splitter), 613609 (55-inch harness/splitter), 640094 (upfitter harness), 640115 (on/off harness) and 640163 (Hi Beam harness/splitter) as compatible products. Those accessory listings do not replace the explicit 640119 recommendation or establish particular built-in lighting modes. None is included.

Marketing describes engineering for racing speeds above 110 mph. This is manufacturer design context, not a guarantee of safe driving speed or visibility under all conditions. This auxiliary bar is not represented as a DOT headlight replacement.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to Baja Designs

Optional accessories

Separately listed covers and guards include 458410 (clear cover), 458411 (black rock guard) and 458412 (amber cover). Listed lens kits are 458113 (clear Spot), 458114 (clear Driving/Combo), 458115 (clear Wide Cornering), 458116 (amber Wide Cornering) and 458117 (amber Driving/Combo). A standard Spot replacement lens is not represented as retaining the supplied Racer Spot pattern. Confirm the quantities needed for the 30-inch bar; accessory counts are not specified. Anti-theft hardware 660302 and 660303 is also listed separately. These accessories are not included contents.

Manufacturer coverage

Baja Designs lists a 30-Day Money Back Satisfaction Guarantee and Limited Lifetime Warranty, subject to its terms.

Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
